Frequency response: 40Hz-18KHz

Directivity angle: H90o×V45o

Long-term power(RMS): 800W/600W（LF,HF/MF）

Peak Power Handling: 3200W/2400W（LF,HF/MF）

Impedance: 8ohms/8ohms（LF,HF/MF）

Sensitivity: 108dB（2.83v/m）

Maximum SPL: 142dB/145dB（LF,HF/MF）

Connection: 2×NL 8 Speakon

Enclosure Construction: 18-Birch Plywood

Cabinet Surface Treatment: Black Catalyzed Polyurethane Paint

Dimensions(H×W×D): 1000×695×760mm

Low: 18 IN×1 (460mm)

Mid: 10 IN×1 (260mm)

High: 3 IN×1 (75mm)

N.W.: 121 Kg
